It is suitable for calibrating and fine sanding laminate lumber, composite board, partical board, solid wood, panel furniture, bamboo floor etc. This machine is one of the necessary equipment for integrated wood and furniture manufacturing.
Heavy duty construction
User friendly
Full electrical PLC control
Panel fully automatic
Cost effective
Stable performance
Speed technology
Vibration free construction
Blower to remove dust
Brusher (optional)
| MODEL | R-RP RXF 130 ( HEAVY DUTY ) |
|---|---|
| Machine Name | Fully Automatic Combine Machine |
| Machine Function | Calibration With Sanding |
| Calibration Roller Diameter | 180 MM |
| Sanding Roller Diameter | 280 MM |
| Working Width | 40 – 1300 MM |
| Working Thickness | 2.5 - 150 MM |
| Feeding Speed | 0-19 M/MIN |
| Calibration Belt Speed | 24 M/SEC |
| Sanding Belt Speed | 18 M/SEC |
| Belt Size | 1330 X 2620 MM |
| Total Power | 40 HP |
| Calibrating Belt Motor Power | 15 HP |
| Sanding Belt Motor Power | 20 HP |
| Feeding Motor Power | 4 HP |
| Up / Down Motor Power | 1 HP |
| Brush Motor | 0.5 HP |
| Working Dry Air Pressure | 0.4 TO 0.8 MPa |
| Machine Weight | ~4000 KG |
