Surfacing-Consistent Uniform Surface
Quality - Finishing due to self dressing
Labours - User friendly can be operate by unskill labour
Life - Longer brush life
Consumable Cost - Very economical due to longer life
Productivity - Increasing the productivity
Maintenance Cost - Maintenance free process
| MODEL | RXF 200 | RXF 400 | RXF 600 | RXF 600 (All-in-one) |
|---|---|---|---|---|
| Operation Type | Sanding | Sanding | Sanding | Sanding + steelwool Combine |
| Brushing roller | 2 Head | 4 Head | 4 Head roller + 2 Cleaning brush | 4 Head Sanding + 2 Head Steelwool |
| Brushing roller size | 210 mm OD X 1250 mm length | 210 mm OD X 1250 mm length | 210 mm OD X 1250 mm length | 220 Dia X 1270 Mm |
| Sanding position | Top & bottom side | Top & Bottom side | Top & Bottom side | Top And Bottom |
| Max. sanding speed | 3 Ply sheet / Minute | 3 Ply sheet / Minute | 3 Ply sheet / Minute | 3 Ply/ Min |
| Sheet thickness for sanding | Min. 4 mm to Max. 52 mm | Min. 4 mm to Max. 52 mm | Min. 4 mm to Max. 52 mm | 5 Mm To 52 Mm |
| Vacuum blower pipe size | 2 Pipe (5 ") | 4 Pipe (4 ") | 2 Pipe (4 "), 2 Pipe (5 ") | 2 Pipe (4 "), 2 Pipe (5 ") |
| Power consumption | 12 Hp (dust collector) | 21 Hp (dust collector) | 21 Hp (dust collector) | 21 Hp (dust collector) |
| Digital thickness meter | Yes (Optional) | Yes (Optional) | Yes (Optional) | Yes (optional) |
