PLYWOOD SIDE EDGE SANDING MACHINE
profile-sanding-machine

Automatic wood brush sanding machine is mainly for the grinding or sanding door, cabinet, plywood, MDF and other panel furniture or solid wood furniture. It is widely applied to the board with primer, PE, PU, UV coating because of its good polishing effect.

  Different layout of brush rollers, support customization.

  We provide high-quality sandpaper-valgro brand imported from India and Hermes brand from Germany for your choice.

  The gantry milling processing for the platform extends the operating life of the linear guideway, and make sure of the sanding precision.

  The speed of rollers are adjustable so that the workers can adjust the speed according to different materials.

  High-quality sand papers valgro brand imported from India.

  The speed of each group of rollers is adjustable.

PLYWOOD-SIDE-EDGE-SANDING-MACHINE



MODEL RXF-1300-6SY
Maximum Working Width 1300 MM
Max. Working Thickness 100 MM
Conveyor Belt Speed 2-12 M/MIN
Longitudinal Roller Motor Power 1.75 HP X 2 NOS
Scrubbing Plate Motor Power 3 HP
Straight Roller Motor Power 3 HP X 2 NOS
Feeding Motor Power 2 HP
Swing Motor Power 1 HP X 3 NOS
Total Motor Power 16 HP
Dust Collector Hopper Size 100 MM X 6 NOS
Machine Size 3000 X 1600 X 1900 MM
